Emerson 21D83M-843 Integrated Furnace Control Kit

Why Use Fans?

fans are a great way to circulate the air in your home or office, especially during those suffocating hot summer days when temperatures are miserable and the air seems stale. Tower fans can help you cool down, and can often get the air flowing better in rooms your air conditioner or swamp cooler doesn't reach.

Emerson 21D83M-843 Integrated Furnace Control Kit will help you clean the air filter. Brings you the fresh air is good for health. Emerson 21D83M-843 Integrated Furnace Control Kit is very good, fit place to live and where you work . We are committed to bring you the best products Emerson 21D83M-843 Integrated Furnace Control Kit

• Replacement for Lennox 10M9301, 12L6901, 32M8801, 56L8401, 24L8501, 63K8901, 97L4801, 100925-01, 100925-03, 17W9201, 23W5101, 30W2501, 69M0801, 69M1501, 83M00
• Replacement for White-Rodgers 50A65-120, 50A65-121, 50A62-120, 50A62-121, 50A62-820, 21D83M-843, 50A66-12
• Input Voltage: 25 VAC 50 / 60 Hz, Maximum Input Current @ 25 VAC: 0.45 amp
• Circulator Relay: 14.5 FLA - 25.0 LRA @ 120 VAC
  Operating Temperature Range: -40 to +175°F (-40 to +79°C)
  Humidity Range: 5% to 93% relative humidity (non-condensing)

WHAT'S INCLUDED IN THE KIT: Kit includes: (1 each) - 50A66-843 Ignition Control Board; (1 each) - Wiring harness (9-pin to 12-pin); (1 each) - Wiring harness (4-pin to 6-pin); (1 each) - Mounting panel; (4 each) - Stand-off fasteners; (1 each) - Circuit breaker; (1 each) - 4" blue wire; (2 each) - Wiring diagrams -- CROSS REFERENCE: Replaces Lennox 10M9301, 12L6901, 32M8801, 56L8401, 24L8501, 63K8901, 97L4801, 100925-01, 100925-03, 17W9201, 23W5101, 30W2501, 69M0801, 69M1501, 83M00; White-Rodgers 50A65-120, 50A65-121, 50A62-120, 50A62-121, 50A62-820, 21D83M-843, 50A66-122, 50A66-123 -- PRODUCT SPECIFICATIONS: Input Voltage: 25 VAC 50 / 60 Hz; Maximum Input Current @ 25 VAC: 0.45 amp; Valve Relay: 1.5 amp @ 25 VAC 50 / 60 Hz 0.6 pf; Ignitor Relay: 2.0 amp @ 120 VAC 50 / 60 Hz (resistive); Inducer Relay: 2.2 FLA - 3.5 LRA @ 120 VAC; Circulator Relay: 14.5 FLA - 25.0 LRA @ 120 VAC; Operating Temperature Range: -40 to +175°F (-40 to +79°C); Humidity Range: 5% to 93% relative humidity (non-condensing) -- TIMING SPECIFICATIONS: Pre-purge: 15; Heat delay to fan ON 45; Heat delay to fan OFF 60/90/120/180; Cool delay to fan ON 2; Cool delay to fan OFF 2/45; Auto reset 60 minutes
